DS-KD8003-IME2

DS-KD8003-IME2 Specifications

• Display Parameters
• Size/
• Operation MethodPhysical button
• Type/

• Video Parameters
• Supplement Light

  IR supplement

  ?

• Lens1
• FOVHorizontal 180?, vertical 96?
• PixelMain stream: 1920 ? 1080, (720p configurable)V; sub stream: 720 ? 480

• Audio Parameters
• Audio QualityNoise suppression and echo cancellation

• Capacity
• Sub Door Station Capacity16

• Network Parameters
• Communication Protocol

  TCP/IP, RTSP

  ?

• Wired NetworkTwo-wire transmission
• Wi-Fi/
• Bluetooth/

• Device Interfaces
• Network Interface0
• Exit Button2
• Lock Control2
• Door Contact Input2
• Power Interface1

• General
• Button1
• InstallationWall mounting
• Indicator0
• /
• Protective LevelIP65
• Power Supply Method

  24 VDC two-wire power supply (< 16 W) or 12 VDC independent power supply (<

  20 W)

  ?

• Working Temperature-40 ?C to 60 ?C (-40 ?F to 140 ?F)
• Working Humidity10% to 95%
• Dimensions

  98 mm ? 99.8 mm ? 43.9 mm (3.86" ? 3.93\" ? 1.73\")

  ?

• Battery/
• Application EnvironmentOutdoor
• Power Consumption4 W
• LanguageEnglish, French, Portuguese (Brazil), Spanish, Russian, German, Italian, polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian
