DS-D5B86RB/A

DS-D5B86RB/A Specifications

• Product Model
• Product ModelDS-D5B86RB/A

• Display
• Screen Size86 inch LED Backlight
• BacklightDLED
• Pixel Pitch0.164(H) ? 0.493(V) mm
• Resolution3840 ? 2160 @60 Hz
• Brightness350 cd/m?2;
• Color Depth10 bit
• Contrast Ratio12001Typ.
• Response Time6 ms
• Color Gamut90% NTSCCIE1931 Typ.
• Refresh Rate60 Hz
• Viewing Angle178?(H)/178?(V)

• Built-In System
• Operation SystemAndroid 8.0
• Processor4-core A73 ? 2 + A53 ? 2, 1.5 GHz
• Memory3 GB
• Built-In Storage32 GB
• NICBuilt-in 100 Mbps NIC, supporting routing

• Touch
• TypeInfrared touch screen
• GlassAG smooth glass
• Touch Point20 point multi-touch
• Touch Response Time 10 ms
• Touch Precision?1 mm (e 90% touching area)
• Touch CraftFull paste

• Internal Function
• LoudspeakerBuilt-in 2 ? 16 W loudspeaker
• BluetoothBuilt-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.0 and previous version.

• Interface
• Video & Audio InputHDMI IN ? 2MAX 4 K @ 60 Hz, LINE IN ? 1
• Video & Audio OutputHDMI OUT ? 1MAX 4K @ 60 Hz LINE OUT ? 1
• Control InterfaceRS-232 ? 1
• Network InterfaceRJ45 (100Mbps ports) ? 2
• Data Transmission Interface2 USB on front panel , 2 USB on rear panel

• Power
• Power Consumption< 420 W (full load)
• Standby Consumption0.5 W

• Working Environment
• Working Temperature0 ~40
• Working Humidity10%~90% RH

• General
• PowerAC 100 V^240 V50/60 Hz
• Product Dimensions1963? 1159 ? 87.5 mm
• Package Dimensions (W ? H ? D)2187 x 1366 x 274mm
• Net Weight65.12 kg
• Gross Weight86.24 kg
