DS-2DF6A436X-AEL(T5)

DS-2DF6A436X-AEL(T5) Specifications

• Camera
• Image Sensor1/1.8" progressive scan CMOS
• Min. IlluminationColor: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @(F1.2, AGC ON), 0 Lux with IR
• Shutter Speed1/1 s to 1/30,000 s
• Slow ShutterYes
• Day & NightIR cut filter
• Zoom36x optical, 16x digital
• DORI

  Detect (25 px/m): 2979.3 m

  Observe (63 px/m): 1182.3 m

  Recognize (125 px/m): 598.9 m

  Identify (250 px/m): 297.9 m

• Max. Resolution2560 ? 1440

• Lens
• FocusSemi-auto, manual, auto
• Focal Length6.0 mm to 216 mm
• Zoom SpeedApprox. 4.5 s
• FOV

  Horizontal field of view: 56.6? to 1.7? (wide-tele),

  Vertical field of view: 33.7? to 0.9? (wide-tele),

  Diagonal field of view: 63.4? to 1.9? (wide-tele)

• ApertureF1.2

• PTZ
• Movement Range (Pan)360?
• Movement Range (Tilt)-20? to 90? (auto flip)
• Pan SpeedPan speed: configurable from 0.1? to 300?/s; preset speed: 540?/s
• Tilt SpeedTilt speed: configurable from 0.1? to 240?/s, preset speed 400?/s
• Proportional PanYes
• Presets300
• Patrol Scan8 patrols, up to 32 presets for each patrol
• Pattern Scan4 pattern scans, record time over 10 minutes for each scan
• Power-Off MemoryYes
• Park ActionPreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
• 3D PositioningYes
• PTZ Status DisplayYes
• Preset FreezingYes
• Scheduled TaskPreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output

• Video
• Main Stream

  50 Hz: 25 fps (2560?1440, 1920?1080, 1280?960, 1280?720)

  60 Hz: 30fps (2560?1440, 1920?1080, 1280?960, 1280?720)

• Sub-Stream

  50 Hz: 25 fps (704 ? 576, 640 ? 480, 352 ? 288)

  60 Hz: 30 fps (704 ? 480, 640 ? 480, 352 ? 240)

• Third Stream

  50 Hz: 25 fps (1920 ? 1080, 1280 ? 960, 1280 ? 720, 704 ? 576, 640 ? 480, 352 ? 288)

  60 Hz: 30 fps (1920 ? 1080, 1280 ? 960, 1280 ? 720, 704 ? 480, 640 ? 480, 352 ? 240)

  ?

• Video Compression

  Main stream: H.265+/H.265/H.264+/H.264

  Sub-stream: H.265/H.264/MJPEG

  Third stream: H.265/H.264/MJPEG

• Video Bit Rate32 Kbps to 16384 Kbps
• H.264 TypeBaseline profile, main profile, high profile
• H.265 TypeMain profile
• Scalable Video Coding (SVC)H.264 and H.265 encoding
• Region Of Interest (ROI)8 fixed regions for each stream

• Audio
• Audio CompressionG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
• Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)

• Network
• Network StorageNAS (NFS, SMB/ CIFS), ANR
• ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour
• APIOpen-ended API, ISAPI, Hikvision SDK, Third-party management platform, ISUP, Open Network Video Interface (Profile S, Profile G, Profile T)
• Simultaneous Live ViewUp to 20 channels
• User/HostUp to 32 users. 3 levels: Administrator, Operator and User
• Smooth StreamingYes
• SecurityUser authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
• ClientiVMS-4200, Hik-Connect, HikCentral
• Web BrowserIE11, Chrome 57.0+, Firefox 52.0+, Safari 11+

• Image
• Day/Night SwitchDay, night, auto, scheduled-switch
• Image EnhancementBLC, HLC, 3D DNR
• Wide Dynamic Range (WDR)140 dB WDR
• DefogOptical defog
• Image StabilizationEIS (Built-in gyroscope to improve EIS performance)
• Regional ExposureYes
• Regional FocusYes
• Privacy Mask24 programmable polygon privacy masks, mask color or mosaic configurable
• SNRe 52 dB

• Interface
• Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
• On-Board StorageBuilt-in memory card slot, support MicroSD/MicroSDHC/MicroSDXC, up to 256 GB; NAS (NFS, SMB/ CIFS), ANR
• Alarm7 alarm inputs, 2 alarm outputs
• Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 K? ? 10%; 1 output (line out), line level, output impedance: 600 ?
• Video Output1.0V[p-p]/75?, PAL, NTSC, BNC connector
• RS-485HIKVISION, Pelco-P, Pelco-D, self-adaptive

• Event
• Basic EventMotion detection, video tampering alarm, alarm input and output, exception
• Smart EventIntrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, vandal-proof alarm, audio exception detection
• Smart TrackingManual tracking, auto-tracking
• Alarm LinkageAlarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.

• Deep Learning Function
• Face CaptureSupport detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture
• Perimeter Protection

  Line crossing, intrusion, region entrance, region exiting

  Support alarm triggering by specified target types (human and vehicle)

• Road Traffic And Vehicle Detection
• Road TrafficSupport vehicle detection (license plate number,vehicle model, and vehicle color recognition)

• General
• General FunctionMirror, password protection, watermark, IP address filter
• Power24 VAC?25% (Max. 45 W, including max. 6 W for heater), Hi-PoE (Max. 50 W, including max. 6 W for heater)
• Operating ConditionTemperature: -40?C to 70?C (-40?F to 158?F), Humidity: d 95%
• Dimension 231.1 mm ? 355.6 mm ( 9.10" ? 14")
• Approx. 6 kg (13.23 lb.)
• Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

• Approval
• EMC

  FCC SDoC (47 CFR Part 15, Subpart B);

  CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014);

  RCM (AS/NZS CISPR 32: 2015);

  IC VoC (ICES-003: Issue 7);

  KC (KN 32: 2015, KN 35: 2015)

• Safety

  UL (UL 62368-1)

  CB (IEC 62368-1:2014+A11);

  CE-LVD (EN 62368-1:2014+A11:2017),

  BIS (IS 13252(Part 1):2010/ IEC 60950-1: 2005);

  LOA (IEC/EN 60950-1)

• Environment

  CE-RoHS (2011/65/EU); WEEE (2012/19/EU);

  Reach (Regulation (EC) No 1907/2006)

• ProtectionLightning Protection, Surge Protection and Voltage Transient Protection, ?6 kV Line to Gnd, ?3kV Line to Line, IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
