DS-2DE7S225MW-AEB(F1)(S5)

DS-2DE7S225MW-AEB(F1)(S5) Specifications

• Camera
• Image Sensor

  [fixed-focal] 1/1.8" progressive scan CMOS;

  [varifocal] 1/2.8 progressive scan CMOS"

• Min. Illumination

  [fixed-focal] Color: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with light;

  [varifocal] Color: 0.005 Lux @ (F1.6, AGC ON); B/W: 0.001 Lux @(F1.6, AGC ON); 0 Lux with IR

• Shutter Speed1/1 s to 1/30000 s
• Slow Shutteryes
• Focussemi-auto,manual,auto
• Day & Night[fixed-focal] 24/7 colorful imaging; [varifocal] ICR
• Day/Night Switchday;night;auto;scheduled-switch
• BLCyes
• WDRdigital WDR
• HLCyes
• 3D DNRyes
• Defogyes
• EISyes
• Regional Exposureyes
• Regional Focusyes
• Image Settingssaturation;brightness;contrast;sharpness
• Image Parameters Switchyes
• White BalanceMWB;indoor;outdoor;fluorescent lamp;sodium lamp;ATW;auto;Locked WB
• Digital Zoom16x
• Optical Zoom25x
• Privacy Maskup to 24 masks;mosaic mask ;mask color configurable;polygon region
• DORI

  Detect (25px/m): 1600.0 m

  Observe (63px/m): 634.9 m

  Recognize (125px/m): 320.0 m

  Identify (250px/m): 160.0 m

• SNR52dB
• General Functionmirror, password protection, watermark, IP address filter

• Lens
• Focal Length

  [fixed-focal] 4 mm;

  [varifocal] 4.8 mm to 120 mm, 25? Optical

• Zoom Speedapprox. 4.4 s
• FOV

  [fixed-focal]

  horizontal field of view: 88.7?,

  vertical field of view: 46.5?,

  diagonal field of view: 105.0?;

  [varifocal]

  Horizontal field of view: 57.6? to 2.5? (wide-tele),

  Vertical field of view: 34.4? to 1.4? (wide-tele),

  Diagonal field of view: 64.5? to 2.9? (wide-tele)

• Aperture

  [fixed-focal] F1.0;

  [varifocal] F1.6

• Illuminator
• White Light DistanceUp to 30 m
• IR DistanceUp to 200 m
• Visual AlarmWhite light

• PTZ
• Movement Range (Pan)360?
• Movement Range (Tilt)-15? to 90? (auto flip)
• Pan Speedpan speed: configurable from 0.1? to 160?/s; preset speed: 240?/s
• Tilt Speedtilt speed: configurable from 0.1? to 120?/s, preset speed 200?/s
• Proportional Zoomyes
• Presets300
• Patrol Scan8 patrols, up to 32 presets for each patrol
• Pattern Scan4 pattern scans
• Power-Off Memoryyes
• Park Actionpreset;patrol scan;pattern scan;auto scan;tilt scan;random scan;frame scan;panorama scan
• 3D Positioningyes
• PTZ Status Displayyes
• Preset Freezingyes
• Scheduled Taskpreset;auto scan;random scan;frame scan;patrol scan;pattern scan;panorama scan;tilt scan;dome reboot;dome adjust;aux output

• Video
• Region Of Interest (ROI)Fixed region,main stream, sub-stream and third stream respectively support eight fixed areas
• Max. Resolution1920 ? 1080
• Stream Typemain stream;sub-stream
• Main Stream

  50 Hz: 25 fps (1920 ? 1080, 1280 ? 960, 1280 ? 720);

  60 Hz: 20 fps (1920 ? 1080, 1280 ? 960, 1280 ? 720)

• Sub-Stream

  50 Hz: 25 fps (704 ? 576, 640 ? 480, 352 ? 288);

  60 Hz: 20 fps (704 ? 480, 640 ? 480, 352 ? 240)

• Video CompressionH.265;H.264;MJPEG
• Video Bit Rate32 kbps - 16384 kbps
• H.264 Typebaseline profile;main profile;high profile
• H.265 Typemain profile
• H.264+yes
• H.265+yes
• SVCyes

• Audio
• Audio CompressionG.711alaw;G.711ulaw;G.722.1;G.726;MP2L2;PCM;AAC
• Audio Bit RateMP2L2: 32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 144 kbps, 160 kbps, 192 kbps; AAC: 16 kbps, 32 kbps, 64 kbps;G.722.1: 16Kbps;G.711ulaw: 64Kbps; G.711alaw: 64Kbps
• Audio Sampling RateMP2L2: 16kHz, 32kHz, 48kHz,AAC: 16kHz, 32kHz, 48kHz,PCM: 8kHz, 16kHz, 32kHz, 48kHz
• Environment Noise Filteringyes

• Smart Features
• Face Captureyes
• Basic Eventaudio exception;motion detection;alarm input;alarm output;video tampering alarm;exception
• Smart Eventintrusion detection;line crossing detection;region entrance detection;region exiting detection;unattended baggage detection;object removal detection
• Smart RecordANR;Dual-VCA
• Warning And Alertwhite light warning;audible warning

• Network
• Network StorageNAS (NFS, SMB/ CIFS);ANR
• ProtocolsIPv4/IPv6;HTTP;HTTPS;802.1x;Qos;FTP;SMTP;UPnP;SNMP;DNS;DDNS;NTP;RTSP;RTCP;RTP;TCP/IP;UDP;IGMP;ICMP;DHCP;PPPoE;Bonjour
• APIHikvision SDK; ISAPI;Hik-Connect;ISUP;Open Network Video Interface
• Simultaneous Live ViewUp to 20 channels
• User/Host32
• Security MeasuresAuthenticated username and password;MAC address binding;HTTPS encryption;802.1X authenticated access;IP address filter
• ClientiVMS-4200;Hik-Connect
• Web BrowserIE10-11, Chrome 57+, Firefox 52+, Safari 12+

• Interface
• Communication InterfaceRJ45, self-adaptive 10M/100M Ethernet port
• On-Board Storagesupport microSD/microSDHC/microSDXC cards, up to 256 GB
• Alarm Input2 alarm inputs
• Alarm Output1 alarm output
• Audio Input1 audio input, 2.0 to 2.4Vp-p, 1k Ohm?10%
• Audio Output1 audio output

• Event
• Alarm LinkagePreset, patrol scan, pattern scan, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, audible warning, white light flashing

• General
• Power24 VAC, Hi-PoE
• Power Consumption And CurrentMax. 42 W, including max. 15 W for supplement light
• Operating Conditions-30 to 65 (-22?F to 149?F) ;humidity lower than 90%RH
• Resetyes
• Demistyes
• MaterialADC12
• Dimensions? 226.1 mm ? 362.5 mm (? 8.9" ? 14.3")
• approx. 4.8 kg (10.58 lb.)

• Approval
• ProtectionIP66, IK10 (excluding glass window), 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
